Industrial 2-Ch RS485 to RJ45 Ethernet Serial Server Dual ETH Ports Dual Channels RS485 Independent Operation Bi-Directional Transparent Transmission

Overview A 2-ch RS485 device data acquisitor / IoT gateway designed for the industrial environment. Dual RS485 can work simultaneously without interfering with each other. It combines multi functions in one, including serial server, Modbus gateway, MQTT gateway, RS485 to JSON, and network switch. The module features dual RS485 and dual Ethernet ports (PoE function optional), uses a DC port (outer diameter: 5.5mm, inner diameter: 2.1mm) and screw terminal for power input. The case with rail-mount support, is small in size, easy to install, and cost-effective. It is suitable for applications like data acquisition, IoT gateway, safety & security IoT, and intelligent instrument monitoring... Package include 1. 2-CH RS485 TO ETH (B) x1

• Industrial Isolated 2-Ch RS485 To RJ45 Ethernet Serial Server: 2-Ch RS485 To Ethernet, Modbus/MQTT/JSON Support, Rail-mount Metal Case
• Industrial Isolated 2-Ch RS485 To RJ45 Ethernet Serial Server: 2-Ch RS485 To Ethernet, Modbus/MQTT/JSON Support, Rail-mount Metal Case
• Multi Power Supply Options: Support PoE Ethernet Port Power Supply*, Suitable For IEEE 802.3af PoE Standard; Support Screw Terminal And DC Power Port For Power Supply, DC 6~45V; Wide Voltage Range Input
• Rail-Mount Support: Industrial-Grade Rail Design, Compact Size, Easy Installation, Cost-Effective
• Modbus Gateway Support: Suitable For Modbus Networking Upgrade, Can Be Used With Specific Configuration Software
